Panels

Tehnix polyurethane insulated panels (TPP) are top-quality products in modern construction. They feature excellent thermal and sound insulation, high load-bearing capacity, quick installation, and long lifespan. Available in various thicknesses and filling variants. In addition to polyurethane, Tehnix manufactures panels with mineral wool insulation (TMP).

This combination does not exist.

Description

Panels with polyurethane insulation represent an exceptionally high-quality solution in the realm of modern construction. Their prominent features include excellent thermal and sound insulation, making these panels an ideal choice for buildings of various purposes. Additionally, the high load-bearing capacity of the panels provides stability to the structure, while quick installation speeds up the construction process. Thanks to their long lifespan, these panels represent a sustainable solution for long-term investment in infrastructure projects.

Advantages and benefits

Exceptional thermal insulation: The panels provide a high level of thermal insulation, effectively reducing heat loss and increasing the energy efficiency of the building.
Excellent sound insulation: In addition to thermal insulation, the panels also offer good sound insulation, reducing sound transmission between rooms.
High load-bearing capacity: The panels are characterized by high load-bearing capacity, contributing to the stability of the structure and supporting various construction requirements.
Quick installation: Panel installation is fast and efficient, resulting in reduced labor costs and accelerated construction time.
Long lifespan: The panels have a long lifespan, reducing the need for regular maintenance and replacement, contributing to the long-term sustainability of the project.
Fire resistance: Variants of panels with PIR insulation can provide a high level of fire resistance, improving the safety of the building.
Variety of thicknesses and colors: Adaptability in panel thickness allows for customization to specific project requirements, while a wide range of colors enables aesthetic customization.
Custom manufacturing: Panels are custom-made to customer specifications, allowing for personalization according to specific dimensions and project requirements.
Use of sophisticated equipment and quality materials: Production involves the use of sophisticated equipment from reputable European manufacturers and the highest quality raw materials, resulting in a premium product.
Wide range of applications: Panels offer a wide range of possibilities in designing architectural solutions for various types of buildings, whether residential, commercial, or industrial projects.

Technical specifications

Panel type	Thickness mm	U-value W/m2 EN12667	U-value W/m2 EN14509	Tezina kg/m2Weight kg/m2	Fire resistance
TMP-60	60	0,64	0,70	17,40	EI-30
TMP-80	80	0,48	0,52	19,90	EI-60
TMP-100	100	0,39	0,41	22,30	EI-90
TMP-120	120	0,33	0,35	24,50	El-120
TMP-150	150	0,26	0,29	28,10	El-120
TMP-180	180	0,22	0,24	31,70	El-120
TMP-200	200	0,20	0,22	34,20	El-120

Panel type	Thickness mm	U-value W/m2 EN12667	U-value W/m2 EN14509	Tezina kg/m2Weight kg/m2
TPP-30	30	0,60	0,70	9,20
TPP-50	50	0,42	0,51	10,00
TPP-60	60	0,34	0,42	10,40
TPP-80	80	0,25	0,31	11,20
TPP-100	100	0,20	0,25	12,00
TPP-120	120	0,17	0,21	12,80
TPP-150	150	0,14	0,17	16,40
